Description
Mr. Spaghetti designed a rather unique light-up badge… let’s just say he didn’t wire the LEDs in the most optimal way. This badge features a 120x24 WS2812B LED matrix that displays a flag. The microcontroller controlling the LED matrix is a WCH CH32V003F4U6.
The PCB fabrication data for this badge and its firmware are available. Will you be able to figure out this flag?
Note: The order of the copper layers follows the standard convention, i.e., F.Cu, In1.Cu, In2.Cu, In3.Cu, In4.Cu puis B.Cu.
The silkscreen Gerber file is not provided; it is up to you to determine the placement and orientation of the components.
Files
-
spaghetti-badge.bin
8.64 KiB – 3fd3b3b29e9309cbe0379eee84193267af437d407fc9b62d5a86a9502cf777a9 -
spaghetti-badge-gerber.tar.xz
1.26 MiB – 6ba4503ad8a7c53e234b48acba1c29b5e9a77172ab7587ca7065de8bc472009f
Author
Flag
Submit your solution
You can submit your writeup for this challenge. Read the FAQ to learn how to proceed.
You need to be logged in to submit a writeup.
Writeups
There are no public solutions for this challenge yet, but you can submit yours after getting the flag.
